Epoch Batteries

48V 60Ah GC2 - Golf Cart LiFePO4 Lithium Battery - Complete Kit - ETA MAR 31

Sale price$1,699.00 Regular price$1,999.00
Save $300.00
No reviews

- PREORDER - ESTIMATED TO SHIP - MARCH 31, 2023
- LiFePO4 Chemistry - Deep Cycle Battery
- 60Ah Capacity
- 120A Max Continuous (200A 10S Pulse)
- IP67 Rated, Dust and WATERPROOF
- CANBUS/RS485 Communication
- Built-in Smart Battery Management System (BMS)
- Over charge and over discharge protection
- Over current and short circuit protection
- High & low temperature disconnects
- 4000+ Cycle life & Maintenance-free
- 11 Year Manufacturer Warranty

Stock:
In stock

Download Files

Whats included

(2) Epoch 48V 30Ah LiFePO4 Module Batteries

(1) Battery Meter Fuel Gauge

(1) 48V 22A Battery Charger - IP67

(1) 48 to 12V Voltage Reducer for connecting accessories

(2) Battery to Battery - CANBUS Communication Cable

(2) 4AWG 24 Inch Wiring

(1) Parallel Busbar

(1) NOCO AC Port Plug

(1) Battery Lifting Strap

Tech Specs

Voltage:

51.2V Nominal

Chemistry:

LiFePO4

Max Charge Voltage:

57.6V

Operating Voltage Range:

40.0 - 57.6V

Ah Capacity:

60Ah

Cell configuration:

16S

Max Continuous Discharge Amps:

120A

Max Discharge Peak Current Amps:

200A (10 Seconds)

Max Charge Current Amps:

60A

Charge Temp Range:

0°C (32°F) / 55°C (131°F)

Discharge Temp Range:

0°C (32°F) / 55°C (131°F)

Storage Temp:

0°C (32°F) / 30°C (86°F) (<6 Months)

Weight:

33 (LBS) (per module x2)

Depth Inches:

7.1 (per module x2)

Width Inches:

10.2 (per module x2)

Height Inches:

10.7 (per module x2)

Safety Features:

BMS (Battery Management System) Over Voltage, Under Voltage, Over-Current, Short Circuit, Over Temperature, Under Temperature

Series | Parallel:

Max (10) in Parallel = 300 Amp Hours

Data Specification Sheet Download:

Click Here

Designed for 48V Golf Carts

TROJAN T-105 EXACT REPLACEMENT

MODULE DESIGN, GC2 SIZE

IP67 - WATERPROOF

STACK FOR INCREASED POWER OUTPUT

CONNECT UP TO 10 IN PARALLEL (300AH)

48V GOLF CARTS

Wiring Diagram

EPOCH LIFEPO4 TECHNOLOGY

At Epoch Batteries, we are excited to offer our customers top-of-the-line lithium iron phosphate (LiFePO4) batteries specifically designed for golf cart applications. Our batteries are engineered to meet the rigorous demands of the golf cart industry, providing exceptional performance, safety, and longevity.

Our LiFePO4 batteries boast outstanding safety features, including built-in protection circuits that prevent overcharging and over-discharging. These features greatly reduce the risk of fires or explosions, making them a reliable choice for golf cart applications where safety is paramount.

Our batteries are also known for their extended lifespan. With a cycle life of up to 4,000 cycles at 80% depth of discharge, they last significantly longer than traditional lead-acid batteries or other lithium-ion batteries. This longevity results in cost savings and reduced downtime for our customers.

Our LiFePO4 batteries are also ideal for golf cart applications due to their higher energy density, which enables them to store more energy in a smaller space. They are also lighter than lead-acid batteries, making them easier to handle and install in golf carts where space is limited.

Our batteries can also operate in a wider range of temperatures than lead-acid batteries, and they can be discharged more deeply without damage. This makes them more efficient for golf cart applications and suitable for use in different environments.

Our LiFePO4 batteries also feature fast charging times and a low self-discharge rate, allowing for more frequent use and longer storage times. With our comprehensive warranty, we stand behind the quality of our batteries and are dedicated to providing the best possible products and services to our customers in the golf cart industry.
